Product Description
The A02B-0120-K842 is a FANUC I/O Link signal cable with JD1A – JD1B 20-pin PCR connectors. It connects the JD1A connector of one module to the JD1B connector of the next, carrying the FANUC I/O Link signal between the CNC/robot controller and remote I/O units. This is a direct OEM-compatible replacement cable.
Key features
- Direct OEM-compatible replacement for FANUC A02B-0120-K842
- FANUC I/O Link signal / communication cable (JD1A – JD1B)
- 20-pin PCR connectors on both ends (JD1A to JD1B)
- 10-core, 0.14 mm² shielded cable (FANUC cable spec A66L-0001-0286)
- Foil-shielded, PVC jacket
- Available in standard lengths (1 m / 5 m / 7 m / 10 m) — confirm length at order
- OEM-compatible replacement; confirm condition and availability before ordering
Compatible Controllers / Robots
Used on FANUC CNC systems and robot controllers with an I/O Link (JD1A / JD1B / JD51A) interface, including FANUC Series 0i / 0i-Mate and 30i/31i/32i CNC, and FANUC robot controllers such as R-30iA / R-30iB. Confirm your controller model and the connector marking on your existing cable before ordering.
Specifications
| Brand | FANUC (OEM-compatible replacement) |
| FANUC Part No. | A02B-0120-K842 |
| Product name | I/O Link cable (signal cable) |
| Cable function | JD1A – JD1B I/O Link signal |
| Connector | 20-pin PCR (JD1A to JD1B) |
| Cable spec | A66L-0001-0286 |
| Core / size | 10-core, 0.14 mm², shielded |
| Jacket | PVC, grey |
| Length | Per order (1 m / 5 m / 7 m / 10 m) |
| Application | FANUC CNC / robot controller I/O Link |
| Condition | Confirm condition at order |
| Warranty | Contact us for details |
FAQ
Are these genuine FANUC parts?
No. These are OEM-compatible replacement parts manufactured to FANUC specifications for maintenance and repair; we primarily supply domestic (non-original) replacements. Please confirm condition and availability with us before ordering.
How do I confirm the correct cable for my system?
Before ordering, verify the FANUC part number on your cable label, your controller / CNC model (e.g. FANUC Series 0i, 0i-Mate, 30i/31i/32i, or robot controller R-30iA / R-30iB), and the connector marking (JD1A / JD1B / JD51A). If you are unsure, send us a photo of the part label and connectors and we will confirm the correct replacement.
What is the lead time and warranty?
Some cables are in stock and ship quickly; most robot cables can be completed within 7 days. Send us your part number and required length and we will confirm current availability, delivery time and warranty terms for your order.
Which cable length should I order?
The A02B-0120-K842 I/O Link cable is available in several standard lengths (e.g. 1 m, 5 m, 7 m, 10 m). Check the length marked on your existing cable or measure the installed run, and order the matching length. If your length is not listed, contact us and we will confirm availability.
Note: FANUC part numbers and model names are used for identification and compatibility reference only. Handsome Cable is an independent supplier and is not affiliated with, authorized by, sponsored by, or endorsed by FANUC.
